Busifire Protection • BAL FZ Rated • Stainless Steel
Australia’s first FZ roller shutters are a tour de force beautifully designed and styled with a touch of elegance stainless steel in look and feel this modern roller shutter is as tough as they come and most importantly will protect your home or business from bushfire.
- Description
- Tech Specs
- Components
- Comparison
- Colours
- Gallery
What seperates BAL FZ Roller Shutters from other shutters
- Comes with a CSIRO test for BAL FZ rating
- Aesthetics: 12 top Colorbond colours for pelmets and guides, shutter colour only available in stainless steel
- Excellent for: Bushfire protection, Security, Light Control & blocking and Noise Reduction
- Good for: Glare reduction, heat and cold transfer reduction and energy savings
BAL FZ Roller Shutter Benefits
- Maximum security
- Up to 85% noise reduction
- Up to 12° cooler in summer
- Up to 12° warmer in winter
- Up to 98% light block out
- Up to 25% more energy efficient
- Secure, built-in locking mechanism
- Eliminates condensation
- Reduces glare
- Rust prevention: 98% components aluminium and stainless steel
Suitable Applications
- Properties with BAL FZ Rating
- Residential Windows
- Residential Doors
- Commercial Windows
- Commercial Doors
- Garage Doors
- Hollow Openings
- Factories & Business Properties
- Alfresco
- Patio
Technical Specifications
Maximum Height | 3800 mm |
---|---|
Maximum Width | 5000 mm |
Curtain Weight | 14 kg per m2 |
Profile Size | 37mm x 9.5mm x 0.6mm Stainless Steel |
Standard Guides | 54mm x 22mm x 1.2mm Aluminium |
Extended Guides | 70mm x 23mm x 2.5mm Aluminium |
Axle | 57mm x 2.1mm Aluminium |
Pelmet Chart
Max Height (Including Pelmet Box) | Pelmet Size |
---|---|
1250mm | 150mm x 150mm |
1660mm | 165mm x 165mm |
2080mm | 180mm x 180mm |
2600mm | 205mm x 205mm |
3630mm | 230mm x 230mm |
Profile
- Type: 37 mm x 9.5 mm x 0.6 mm stainless steel slats
- Insulation: High density injected foam
- Brand: Heroal
- Country of Origin: Germany
Pelmet
- Type: 0.78 mm Aluminium
- Brand: Expalum
- Country of Origin: Spain
Motor
- Type: 240 volt mains tubular
- Brand: ASA
- Country of origin: Italy
Benefit | BAL 29 | BAL 40 | BAL FZ |
---|---|---|---|
Security | ⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ |
Summer Insulation | ⭐⭐⭐⭐⭐ | ⭐⭐⭐ | ⭐⭐⭐⭐⭐ |
Winter Insulation | ⭐⭐⭐⭐⭐ | ⭐⭐⭐ | ⭐⭐⭐⭐⭐ |
Noise Reduction | ⭐⭐⭐⭐ | ⭐⭐⭐ | ⭐⭐⭐⭐⭐ |
Privacy | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ |
Light Control | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ |
Energy Savings | ⭐⭐⭐⭐ | ⭐⭐⭐ | ⭐⭐⭐⭐⭐ |
Bushfire Protection | ⭐⭐⭐ | ⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ |
Wind Protection | ⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ |
Slat Colors
Anodised
