Max Span Roller Shutters

Widespan • Insulated • Secure

This max span aluminium roller shutter is an ideal roller shutter for residential and commercial applications with wide openings. Excellent for garage doors, patios and alfrescos.

What seperates Max Span from other shutters

  • Aesthetics: Double coated + lacquer for abrasion resistant finish
  • Strength: 77mm x 18.5mm foam filled high quality aluminium profiles engineered for extra strength
  • Excellent for: home & business security, light blocking, noise reduction, climate control, energy savings
  • Good for: glare reduction light control and light blocking

Max Span Roller Shutter Benefits

  • Up to 85% noise reduction
  • Up to 15° cooler in summer
  • Up to 15° warmer in winter
  • Up to 98% light block out
  • Up to 45% more energy efficient
  • Secure, built-in locking mechanism
  • Eliminates condensation
  • Reduces glare
  • Rust prevention: 90% components aluminium

Suitable Applications

  • Large Hollow Openings
  • Garage Doors
  • Commercial Windows
  • Commercial Doors
  • Shopfronts
  • Alfreso
  • Patio

Technical Specifications

Maximum Height 3000 mm
Maximum Width 5900 mm (Including the guides)
Curtain Weight 5.5 kg per m2
Profile Size 77mm x 18.5mm Aluminium
Widespan Guides 105mm x 37mm Aluminium
Bottom Bar 106mm x 19mm Aluminium

Pelmet Chart

Max Height (Including Pelmet Box) Pelmet Size
2000mm 250mm x 250mm
3200mm 300mm x 300mm



Profile

  • Type: 77mm x 18.5mm Aluminium Interlocking slats
  • Insulation: Polyurethane filled
  • Brand: Ultimate
  • Country of Origin: Australia

Pelmet

  • Type: 0.78 mm Aluminium
  • Brand: Expalum
  • Country of Origin: Spain

Motor

  • Type: 240 volt mains tubular
  • Brand: ASA
  • Country of origin: Italy
Benefit Slimline Fortress Cyclone Patiomate Maxspan Clear Polycarb Manual Push Pull
Security ⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐ ⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐ ⭐⭐⭐
Summer Insulation ⭐⭐⭐⭐⭐ ⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐ ⭐⭐⭐⭐
Winter Insulation ⭐⭐⭐⭐⭐ ⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐ ⭐⭐⭐⭐
Noise Reduction ⭐⭐⭐⭐ ⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐ ⭐⭐⭐
Privacy ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐
Light Control ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐
Energy Savings ⭐⭐⭐⭐ ⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐ ⭐⭐⭐
Bushfire Protection ⭐⭐ ⭐⭐⭐ ⭐⭐ ⭐⭐ ⭐⭐ ⭐⭐
Wind Protection ⭐⭐⭐ ⭐⭐⭐⭐⭐ ⭐⭐⭐⭐ ⭐⭐⭐ ⭐⭐⭐⭐ ⭐⭐ ⭐⭐⭐
Slat Colors
Cream Cream
Clear Beige Clear Beige
White White
Surfmist Surfmist
Shale Grey Shale Grey
Brown Brown
Monument Monument
Silver Silver
Woodland Grey Woodland Grey
